infocus projector user guide

This user guide provides instructions on how to set up, operate, and maintain your InFocus projector. It covers topics such as positioning the projector, connecting power and computer sources, displaying an image, replacing the projector lamp, and turning off the projector. You can find additional information and support on the InFocus website.

Introduction

Welcome to the world of InFocus projectors, where innovation meets performance. InFocus Corporation, a leading innovator in projection and display technologies, is dedicated to providing high-quality, affordable projection solutions for various applications. Whether you’re setting up a home theater, creating a dynamic classroom environment, or delivering impactful presentations, InFocus projectors offer a reliable and user-friendly experience. This user guide provides comprehensive instructions and helpful tips to make the most of your InFocus projector.

We’re confident that your InFocus projector will exceed your expectations. Its advanced features and intuitive design ensure a seamless setup and operation. From connecting your computer and displaying images to replacing the projector lamp and troubleshooting common issues, this user guide equips you with all the knowledge you need to enjoy a brilliant projection experience.

InFocus stands behind its products with exceptional customer support. If you have any questions or need assistance, please visit our website or contact our dedicated support team. We’re here to ensure your satisfaction and help you achieve exceptional projection results.

Positioning the Projector

Proper projector placement is crucial for optimal image quality and viewing experience. Consider these factors when positioning your InFocus projector⁚

• Distance from the screen⁚ The distance between the projector and the screen determines the projected image size. Consult your projector’s specifications for recommended throw ratios and adjust the distance accordingly.
• Screen size⁚ Choose a screen size that comfortably accommodates your audience. A larger screen allows for a more immersive viewing experience, but it may require a greater projector throw distance.
• Projection surface⁚ Project onto a smooth, white surface for optimal image clarity. Avoid projecting onto textured walls or surfaces that may distort the image.
• Ambient light⁚ Minimize ambient light in the projection area to enhance image contrast and visibility. Consider using blackout curtains or blinds to reduce glare.
• Ventilation⁚ Ensure adequate ventilation around the projector to prevent overheating. Leave sufficient space around the projector’s vents for proper airflow.
• Stability⁚ Place the projector on a stable surface to prevent it from tipping over. Use a tripod or mounting bracket for added stability, especially if the projector is placed high above the ground.

By carefully considering these factors, you can position your InFocus projector for a projection experience.

Ceiling Mount

Installing your InFocus projector on the ceiling offers several advantages, including space-saving, aesthetic appeal, and improved viewing angles. Here’s a guide to ceiling mounting your projector⁚

1. Choose a suitable ceiling mount⁚ InFocus recommends using approved ceiling mounts for proper fitting, ventilation, and installation. Consider the projector’s weight and dimensions when selecting a mount.
2. Determine the mounting location⁚ Carefully choose the ceiling location for the projector, ensuring it’s positioned for optimal projection angle and distance from the screen. Consider factors like ceiling height, obstructions, and wiring access.
3. Install the ceiling mount⁚ Follow the manufacturer’s instructions for installing the ceiling mount securely to the ceiling joists or structural support. Ensure the mount is level and stable.
4. Mount the projector⁚ Attach the projector to the ceiling mount, following the projector’s installation instructions. Ensure the projector is properly aligned and secured to the mount.
5. Connect cables⁚ Run the necessary cables from the projector to the power source, computer, or other devices, ensuring they are neatly routed and secured.
6. Adjust the projector⁚ Once mounted, adjust the projector’s lens shift and keystone correction settings to ensure a rectangular image on the screen.
7. Test the installation⁚ Turn on the projector and test the image projection. Make any final adjustments to the projector’s position or settings as needed.

For detailed instructions on ceiling mounting your specific InFocus projector model, refer to the projector’s user manual or the ceiling mount’s installation guide.

Connecting Power

Providing power to your InFocus projector is a crucial step in setting it up. Here’s a step-by-step guide to connect your projector to a power source⁚

1. Locate the power input⁚ Identify the power input port on the back or side of your projector. It is typically marked with a power symbol or “AC IN” label.
2. Use the provided power cord⁚ Ensure you’re using the power cord that came with your InFocus projector. Using a different cord could damage the projector.
3. Connect the power cord⁚ Plug one end of the power cord into the power input port on the projector and the other end into a standard wall outlet.
4. Verify the power connection⁚ Check that the power cord is securely plugged into both the projector and the wall outlet. You should see a power indicator light on the projector illuminating, indicating that it’s receiving power.
5. Turn on the projector⁚ Once the projector is connected to power, press the power button on the projector or its remote control to turn it on.
6. Check the power supply⁚ Ensure that the power source you’re using is compatible with the voltage requirements of your InFocus projector. Refer to the projector’s user manual for specific power specifications.
7. Avoid power surges⁚ Protect your projector from power surges by using a surge protector. This helps prevent damage to the projector’s electronics.

If you experience any issues with the power connection, check the power cord for any damage, ensure the wall outlet is working, and consult your projector’s user manual for troubleshooting tips.

Connecting a Computer Source

To display content from your computer on the projector, you need to connect them using the appropriate cable. The connection method depends on the ports available on both your computer and projector. Here’s a step-by-step guide⁚

1. Identify the connection type⁚ Determine the available ports on both your computer and projector. Common options include VGA, HDMI, and DVI.
2. Choose the right cable⁚ Select the appropriate cable based on the connection type identified in step 1. For example, if both your computer and projector have HDMI ports, use an HDMI cable.
3. Connect the cable⁚ Plug one end of the cable into the corresponding port on your computer (e.g., HDMI on the computer) and the other end into the matching port on your InFocus projector (e.g., HDMI on the projector).
4. Turn on the projector⁚ Ensure that the projector is turned on.
5. Select the input source⁚ On the projector’s remote or keypad, press the “Source” button. Navigate through the available input sources until you find the one corresponding to the connection you just established (e.g., HDMI).
6. Adjust the projector settings⁚ You may need to adjust the projector’s settings, such as resolution and aspect ratio, to match the output of your computer. Refer to the projector’s user manual for detailed instructions.
7. Verify the connection⁚ Once the connection is established, you should see the computer’s desktop or the content you’re trying to display projected on the screen.

If you have any trouble connecting your computer, check the cable for damage, ensure the ports on both devices are working correctly, and consult your projector’s user manual for further assistance.

Optional Computer Connections

While a basic connection between your computer and InFocus projector can be achieved with a single cable, there are optional connections that enhance your projection experience. These connections can improve audio quality, provide additional control options, or offer a more versatile setup.

• Audio Cable⁚ For a more immersive audio experience, connect external speakers to the projector using an audio cable. This will separate the audio signal from the video signal, allowing for better sound quality. Look for an audio output port on the projector and connect it to the speakers.
• USB Cable⁚ A USB cable can be used to connect your computer to the projector for a variety of purposes. It can enable control of the projector using your computer, transfer files between the devices, or provide power to peripherals connected to the projector.
• Ethernet Cable⁚ If you want to connect your projector to a network, you can use an Ethernet cable. This allows you to access files on a network drive, stream content from online services, or control the projector remotely.
• Wireless Adapter⁚ Some InFocus projectors come equipped with built-in Wi-Fi capabilities, while others may require a separate wireless adapter. This allows you to connect your projector to a network without using a cable.

The specific optional connections available on your InFocus projector will vary depending on the model. Refer to your projector’s user manual for a comprehensive list of available connections and their functionalities.

Displaying an Image

Once your InFocus projector is connected to a computer or video source and powered on, you’re ready to display an image. Follow these steps to ensure a successful projection⁚

1. Power On⁚ Press the Power button on the projector’s remote control or keypad to turn it on. The projector lamp will illuminate and the fans will start running to cool the unit.
2. Select Source⁚ The projector may automatically detect the connected source. If not, use the Source button on the remote or keypad to select the correct input. You’ll typically see options like “HDMI,” “VGA,” or “USB.”
3. Adjust Focus and Zoom⁚ The projected image might appear blurry or distorted. Use the focus ring and zoom controls on the projector lens to adjust the sharpness and size of the image.
4. Optimize Image Settings⁚ Most InFocus projectors have settings that allow you to fine-tune the image quality. These settings might include brightness, contrast, color, and aspect ratio. Adjust them to your preference for optimal viewing.
5. Position for Best Viewing⁚ For the best viewing experience, position the projector at the correct distance from the screen and at a suitable angle. Refer to the user manual for recommended distances and angles.

If the image doesn’t appear on the screen or if you encounter any issues, consult the troubleshooting section in your projector’s user manual or visit the InFocus website for support.

Projector Lamp Replacement

The projector lamp is a crucial component of your InFocus projector, responsible for illuminating the image. Over time, the lamp will gradually lose brightness and eventually burn out. When this happens, you’ll need to replace it with a new lamp. Here’s how to replace the lamp⁚

1. Turn Off and Unplug⁚ Before attempting any lamp replacement, ensure the projector is completely powered off and unplugged from the power outlet. Allow the lamp to cool down completely before proceeding.
2. Locate the Lamp Cover⁚ The lamp cover is typically located on the top or side of the projector. It might have a latch or release mechanism.
3. Remove the Lamp Cover⁚ Gently open the lamp cover and remove the old lamp. Be careful not to touch the lamp glass with your bare hands as this can leave fingerprints that can affect lamp performance.
4. Install the New Lamp⁚ Insert the new lamp into the lamp housing, ensuring it’s properly aligned. Make sure the lamp is securely in place.
5. Replace the Lamp Cover⁚ Close the lamp cover and latch it securely.
6. Plug in and Power On⁚ Plug the projector back into the power outlet and turn it on. The new lamp should now be operational.

It’s important to use an InFocus-approved replacement lamp for your projector model. Using a non-compatible lamp can damage the projector or void the warranty. You can purchase replacement lamps directly from InFocus or from authorized retailers.

Turning Off the Projector

Turning off your InFocus projector is a straightforward process, but it’s important to follow the correct steps to ensure the longevity of your projector. Improper shutdown can lead to overheating and potential damage. Here’s how to properly turn off your InFocus projector⁚

1. Press the Power Button⁚ Locate the Power button on either the projector’s remote control or on the projector itself. Press and hold the Power button until the projector begins to shut down.
2. Wait for Cooling⁚ After the projector lamp turns off, the cooling fans will continue to run for a short period to allow the lamp and internal components to cool down. Do not unplug the projector until the fans have stopped running.
3. Unplug the Projector⁚ Once the fans have stopped, unplug the projector from the power outlet.
4. Optional⁚ Cover the Lens⁚ To protect the projector lens from dust and debris, you can optionally cover the lens with a lens cap or a soft cloth.

By following these steps, you can ensure that your InFocus projector is safely turned off and ready for its next use. Remember to always refer to the user manual for specific instructions tailored to your projector model.

Safety Instructions

Your safety and the safety of those around you are paramount when using your InFocus projector. Please read and understand the following safety instructions carefully before setting up and operating your projector. Failure to follow these instructions could result in personal injury, property damage, or damage to the projector itself.

1. Ventilation⁚ Ensure adequate ventilation around the projector to prevent overheating. Do not place the projector on soft surfaces or in enclosed spaces. Allow at least 12 inches (30 cm) of clearance on all sides of the projector.
2. Power Source⁚ Use only the power source specified in the user manual. Do not use damaged or frayed power cords.
3. Lamp Replacement⁚ The projector lamp generates high heat. Never touch the lamp while it is hot. Allow the lamp to cool down completely before replacing it. Always use genuine InFocus replacement lamps.
4. Lens⁚ Do not look directly into the projector’s lens. The intense light can cause eye damage.
5. Children and Pets⁚ Keep children and pets away from the projector. The projector can be a potential hazard if not handled properly.
6. Cleaning⁚ Unplug the projector from the power outlet before cleaning it. Use a soft, dry cloth to clean the exterior of the projector. Do not use any abrasive cleaners or solvents;
7. Professional Service⁚ Do not attempt to repair or modify the projector yourself. Contact InFocus customer support for any repairs or service.

By following these safety instructions, you can ensure a safe and enjoyable experience using your InFocus projector.

User Manual

The InFocus projector User Manual is your comprehensive guide to understanding and operating your projector. This essential document provides detailed information on every aspect of your projector, from initial setup to advanced features and troubleshooting. It’s designed to help you get the most out of your InFocus projector and ensure you’re using it safely and effectively.

The User Manual covers a wide range of topics, including⁚

• Projector Overview⁚ Learn about the projector’s features, specifications, and components.
• Setup and Installation⁚ Detailed instructions on how to connect the projector, adjust the image, and configure settings;
• Operation⁚ Learn how to navigate the projector’s menus, control the image, and use various input sources.
• Advanced Features⁚ Explore advanced settings like picture modes, aspect ratio, and keystone correction.
• Troubleshooting⁚ Find solutions to common issues, such as image problems, connectivity problems, or lamp issues.
• Maintenance⁚ Learn how to clean your projector, replace the lamp, and perform other routine maintenance tasks.
• Safety Instructions⁚ Important guidelines for safe operation of your projector.

The User Manual is available in multiple languages and can be accessed online or downloaded as a PDF file. It’s a valuable resource that will help you maximize your InFocus projector’s performance and ensure a satisfying viewing experience.
